Project Description
Certificate: ISO
Standard: BS EN 14384, EN 1074-6
Connection: Base flanged as EN 1092-2 PN 16, ASME B16.5 Class 150, etc.
W. pressure: 16 bar / 20 bar
Temperature: 4°C to 70°C
Surface: Red powder coating (RAL 3000)
Product Details
Pillar fire hydrant emerges from below ground level in column shape, and is to supply water to firefighting equipment. For wet pillar fire hydrant, it is normally used in nonfrozen areas and the column remains full of water.
Available size (Source 1 with ISO)
| Inlet flange | Body material | Way of outlet | Hose outlet | Pumper outlet | Monitor flange | Ref. No. |
|---|---|---|---|---|---|---|
| DN 100 | Ductile iron | 2-way | (2) 2.5″ BS336 landing valve | / | / | FE0101 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ BS336 landing valve (BSI) | / | / | FE0102 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ BS336 landing valve (LPCB) | / | / | FE0103 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ Storz landing valve | / | / | FE0104 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ BS336 | / | / | FE0105 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ Storz | / | / | FE0106 |
| DN 100 | Ductile iron | 2-way | (2) 2.5″ BS336 PRV | / | / | FE0107 |
Available size (Source 2 with ISO)
| Inlet flange | Body material | Way of outlet | Hose outlet | Pumper outlet | Monitor flange | Ref. No. |
|---|---|---|---|---|---|---|
| DN 100 | Gray cast iron | 2-way | (2) 2.5″ BS336 landing valve | / | / | FE0121 |
| DN 100 | Gray cast iron | 2-way | (2) 2.5″ BS336 pressure regulating valve | / | / | FE0122 |
| DN 150 | Gray cast iron | 3-way | (2) 2.5″ BS336 landing valve | (1) 4″ BSRT | / | FE0123 |
| DN 150 | Gray cast iron | 3-way | (2) 2.5″ BS336 landing valve (LPCB) | (1) 4″ BSRT | / | FE0124 |
| DN 150 | Gray cast iron | 3-way | (2) 2.5″ Storz landing valve | (1) 4″ Storz | / | FE0125 |
| DN 100 | Carbon steel | 2-way | (2) 2.5″ BS336 landing valve | / | / | FE0126 |
| DN 100 | Carbon steel | 2-way | (2) 2.5″ BS336 landing valve | / | DN 100 | FE0127 |
| DN 150 | Carbon steel | 2-way | (2) 2.5″ BS336 landing valve | / | / | FE0128 |
| DN 150 | Carbon steel | 2-way | (2) 2.5″ BS336 landing valve | / | DN 100 | FE0129 |
Note: For FE0126 and FE0128, a monitor flange DN100 (ASME B16.5 Class 150 or EN 1092 PN16) is fitted on the top of the hydrant, so to connect additional fire monitor.
